Review: Bluetone Fried Eye 2+2 Reverb

bluetone-fried-eye-22-logo

OK, people, let’s go wild here and start with the summary for a change:

In my view the good people at Bluetone Amps have outdone themselves with their Fried Eye 2+2 Reverb Combo.

I will stick my neck out really far by claiming that the Fried Eye 2+2 is the best-sounding and most-versatile compact two-channel boutique valve combo I’ve ever come across. This guitar combo is all tone and no hype!

If the demo video and this summary are enough to whet your appetite, I’d suggest you head over to Bluetone Amps’ website right away.

If you want to know more, read on…

****

bluetone-fried-eye-22-front-angle-1

Helsinki-based Bluetone is a small boutique amp maker that handcrafts each and every one of their guitar and bass amplifiers, combos and cabinets. Bluetone offers a wide range of customisable options, both on the electronic as well as on the cosmetic front.

Our review combo (price of this version: 2,400 €; incl. footswitch and cover) is a two-channel all-valve affair comprising a Bluetone Clean channel partnered with a Fried Eye crunch channel, which is Bluetone’s take on the hot-rodded Marshall theme.

The 2+2-monicker in the combo’s name points to the special power amp architecture applied here. Instead of trying to emulate or approximate the different power amp sounds of, say, a Blackface-style clean channel and a Marshall-style crunch channel using heavy filtering and electronic trickery, Bluetone Amps go for maximum authenticity.

The 2+2 power amp uses two different pairs of output tubes – one pair for each channel. Selecting the clean channel switches on the power amp’s pair of 6L6GC-valves, while switching over to the Fried Eye channel will see a pair of EL34s spring into action.

bluetone-fried-eye-22-electronics

(Photo courtesy of Bluetone Amps)

Bluetone Amps have recently been moving away from building their complete model range using only point-to-point building techniques. Certain models are now available as modular designs, which makes production less time-consuming, and thus more affordable. Still, like the point-to-point amplifiers, Bluetone hand-solders all its PCB-based modules at their workshop.

The Fried Eye 2+2 Reverb has been made in this modular fashion.

blutetone-fried-eye-22-reverb-back

Like most Bluetone combos the Fried Eye is constructed with an open back.

bluetone-fried-eye-22-celestion-speaker

Our review sample is one of the first Bluetone amps to feature a Celestion neodymium speaker.

The 12-inch G12 NEO promises genuine Celestion Creamback tones coupled with the benefit of considerably lighter weight.

The Fried Eye 2+2 Reverb uses an MOD reverb tank and Bluetone’s own valve-driven circuitry.

bluetone-fried-eye-22-back-panel

This Fried Eye combo comes with some interesting back panel features:

There’s a Front End signal booster, amplifying the signal right at the beginning of the signal path.

The Fried Eye’s switchable effects loop is an active affair, complete with a dedicated level control. If you don’t run any effects in the loop, you can use the loop’s make-up gain as an additional, foot-switchable boost in the signal path.

bluetone-fried-eye-22-pedalboard

A chunky three-button footswitch unit is supplied with the Bluetone combo.

****

bluetone-fried-eye-22-control-panel

Bluetone’s Fried Eye 2+2 Reverb combo offers a wide range of options on its front panel. Thanks to the logical layout and the clear lettering, the front panel never seems complex or crowded, though.

The Fried Eye Crunch channel offers you a 3-Band EQ-section, plus Fat and Bite switches, to fine-tune your crunch tones.

The Bluetone Clean channel’s High/Low-switch offers two different pre-gain settings, which change the amount of available clean headroom.

Each channel features its own reverb level knobs – so you don’t have to compromise lush reverbs for clean tones with drier settings for crunch – as well as dedicated master volume controls.

Using all the different front panel and back panel features offers you a mind-boggling array of different tonal and drive options. With just a couple (or three) well-chosen guitars, Bluetone’s Fried Eye 2+2 Reverb will give you access to virtually any classic guitar tone you could dream up (with the exception of contemporary Metal).

Bluetone’s clean channel will take you from pristinely shimmering cleans well into Blues break-up territory.

This clip steps through the different boost options offered by the Fried Eye’s clean channel (using a Hamer USA Studio Custom). The sequence is Low dry –> Low plus reverb –> High –> High + FE Boost –> High + FE Boost + FX Boost:

Being able to use the FX loop as an additional booster turns the Fried Eye 2+2 into a two-channel-plus-solo-boost machine.

This clip steps through the different boost options offered by the Fried Eye’s crunch channel (using a Hamer USA Studio Custom). The sequence is Crunch –> Crunch + FE Boost –> Crunch + FE Boost + FX Boost:

Cleaning up the crunch channel using your guitar’s volume control works like a dream here. The Bluetone’s Fried Eye Crunch sounds juicy and lively, even with the guitar turned down to almost zero:

The demo track’s rhythm guitar parts were played on a Gibson Melody Maker SG (stereo left) and a maple-necked Fender Stratocaster (stereo right). The lead part was recorded with a modern Tele-type guitar, using the instrument’s volume control to adjust the amount of overdrive:

****

bluetone-fried-eye-22-front-angle-2

In my view the good people at Bluetone Amps have outdone themselves with their Fried Eye 2+2 Reverb Combo.

I will stick my neck out really far by claiming that the Fried Eye 2+2 is the best-sounding and most-versatile compact two-channel boutique valve combo I’ve ever come across. This guitar combo is all tone and no hype!

Messrs. Kneckt and Vauhkonen don’t run around wearing strange clothes or wild hairdos, pretending to be exalted tone gurus. You also won’t be required to send in mp3s of your guitar playing to prove you’re worthy to join the ”Bluetone Cult”.

Bluetone’s dynamic duo are down-to-earth guys, out on an ongoing quest to bring you maximum tone and usability, and no bullsh*t.

For a genuine boutique-grade amp of its calibre, I can only call the Bluetone Fried Eye 2+2 Reverb’s price tag extremely fair.

****

Bluetone Fried Eye 2+2 Reverb Combo

This version: 2,400 € (including footswitch unit and dust cover)

Contact: Bluetone Amps

Pros:

+ handmade in Finland

+ lightweight

+ multiple boost stages

+ versatility

+ reverb sound

+ dedicated reverb and master controls for each channel

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

17/02/2017

Bluetone Fried Eye 2+2 Reverb – now on SoundCloud

Contact: Bluetone Amps

Save

16/02/2017

First View: Bluetone Fried Eye 2+2 Reverb

Bluetone Fried Eye 2+2 Reverb

• Handmade in Finland
• Two-channel valve amp
• Class AB
• 20-40 W
• 5 x 12AX7 plus 1 x 12AT7
• Two pairs of power amp valves – 2 x 6L6GC (Clean channel) and 2 x EL34 (Crunch channel)
• Switchable boost
• Switchable effects loop
• Switchable spring reverb
• Single Celestion G12 Neo speaker

****

Demo Track
• Two rhythm guitars (Clean channel) – Gibson Melody Maker SG (left) and Fender Stratocaster (right)
• Lead guitar (Crunch channel) – modern Tele-type guitar

Contact: Bluetone Amps

Save

15/02/2017

Bluetone Fried Eye 2+2 ^^^ Testi tulossa! ^^^ Review coming soon!

bluetone-fried-eye-22-front-angle-2

Contact: Bluetone Amps

Save

03/12/2016

Testipenkissä: Fender Bassbreaker 18/30 Combo

fender-bassbreaker-18_30-top-logo

Kuvitellaan, että olemme läsnä Fender vahvistinosaston aivoriihessä lämpimässä Kaliforniassa, syksyllä 1966. Sessiossa on tarkoitus ideoida uutta vahvistinsarjaa.

Yksi osallistujista sanoo: ”Hei, tyypit. Jotenkin alkaa tympiä se, että teemme koko ajan vain vahvistimia country-kitaristeille ja tylsille viihdyttäjille. Miten olisi, jos tekisimme sarjan kitaravahvistimia, joissa olisi vähän enemmän ’munaa’ Blues- ja Rock-väelle? Kuulin pienestä englantilaisesta firmasta, joka rakentaa tuunattuja Bassman-kopioita, ja jengi tykkää. Meilläkin pitäisi olla tällaisia hot-rod-vahvistimia!”

Tällaista kokousta ei koskaan pidetty…

****

fender-bassbreaker-18_30-front

Uusi Fender Bassbreaker 18/30 -kombo (suositushinta: 799 €) olisi voinut olla tämän kuvitteellisen aivoriihen tulos.

Fenderin Bassbreaker 18/30 on kuin se olisi ilmestynyt jostain rinnakkaistodellisuudesta, jossa firma olisi 60-luvun lopulla päättänyt valmistaa amerikkalaisia putkivahvistimia selvällä ”brittikorostuksella”.

Uutuus on kahdella 12-tuumaisella elementillä varustettu Fender-kombo uudella, tyylikkäällä Gray Tweed -päällysteellä. Kaiutinkotelo on rakennettu laadukkaasta koivuvanerista, minkä ansiosta isokokoisen kombon paino jää alle 23 kilon.

fender-bassbreaker-18_30-top

Bassbreakerin mallitunnus ”18/30” viittaa siihen, että kombon kaksi kanavaa ovat käytännössä kaksi erillistä vahvistinta:

Ykköskanava (Channel One) perustuu Fender Blackface Deluxe -vahvistimeen, ja sen pääteteho on 30 wattia. Kakkoskanava (Channel Two) sen sijaan on kevyesti modattu versio hieman aikaisemmasta, ruskeasta Deluxesta. Kakkoskanavan pääteteho on 18 wattia.

fender-bassbreaker-18_30-back

Uusi Bassbreaker on A/B-luokan täysputkivahvistin puolijohdetasasuuntajalla.

Etuaste on rakennettu kahden 12AX7-putken ympärille, kun taas pääte saa tehonsa neljästä EL84-putkesta. EL84 mielletään yleisesti brittivahvistimiin – perinteisesti Fenkuissa, kuten muissakin jenkkivahvistimissa, käytetään 6V6- tai 6L6-pääteputkia.

Takapaneelista löytyy lisäkaappilähdön ja linjalähdön (päätevahvistimen jälkeen) lisäksi myös jakki pakettiin kuuluvalle jalkakytkimelle.

fender-bassbreaker-18_30-valves-and-speakers

”Brittipäätteen” lisäksi Bassbreaker 18/30 -kombossa myös kaiutinvalinta on ei-perinteinen. 60-luvun Fendereistä tuttujen Jensen- tai JBL-kaiuttimien sijaan uutuusvahvistimeen on asennettu pari 12-tuumaista Celestion V-Type -kaiutinta.

****

fender-bassbreaker-18_30-control-panel

Ykköskanavan (”Blackface”) enimmäkseen puhtaita soundeja varten on varattu kolmialueinen taajuuskorjainosasto, kun taas kakkoskanavasta (”Brownface”) löytyy ainoastaan yksi Tone-säädin.

fender-bassbreaker-18_30-angle-2

Tärkein asia ensin – Fender Bassbreaker 18/30 on uskomattoman kovaääninen! Kyseessä on aito non-master-volume-putkikone, joka liikkuu samassa teholuokassa esimerkiksi Marshall 1962 Bluesbreakerin tai Vox AC30:n kanssa.

Kerrostaloasuntoon 18/30 ei todellakaan sovi, koska kakkoskanavan herkulliset särösoundit heräävät henkiin vain kovalla volyymillä. Ja tämä vaikka kombo toimiikin silloin ainoastaan kahdella pääteputkella, minkä vuoksi teho laskee 18 wattiin ja päätevahvistimen puhdas headroom on hyvinkin rajallinen.

Jos Bassbreaker-mallisto kiinnostaa, mutta tämän kombon äänekkyys ei tunnu sopivan käyttötarkoitukseen, kannattaa kokeilla saman sarjan Bassbreaker 15 -komboa, jossa on mm. master volume -säädin.

Pienillä Volume-asetuksilla molemmista Bassbreaker 18/30 –kanavista saa puhtaita soundeja. Channel One on kaksikosta se helisevämpi ja kirkkaampi, kun taas Channel Two on hieman pyöreämpi ja rouheampi. EL84-pääteputkien ja Celestion-kaiuttimien ansiosta uutuuskombon perussoundi ei ole pikkutarkka kopio firman vanhoista klassikkomalleista, vaan todella herkullinen sekoitus 1960-luvun Fender-soundeista ja perinteisten brittikombojen keskialueen murinasta ja potkusta.

Tässä lyhyt pätkä puhtailla asetuksilla (molemmat volume-säätimet kello yhdeksän ja kymmenen välillä), vaahterakaulaisella Fender Stratocasterilla soitettuna:

Demobiisissä soi kaksi komppikitaraa – Gibson Les Paul Junior (Channel One, oikea stereokanava) ja Fender Telecaster (Channel Two, vasemmalta) – sekä Epiphone Les Paul Standard -kitaralla (vintage-tyylisillä EMG HZ -mikrofoneilla) soitettu soolokitara (Channel Two, volume-säädin kello kolme):

****

fender-bassbreaker-18_30-angle-1

Fenderin Bassbreaker 18/30 on oikein mainio ja kovaääninen putkivahvistin sellaisille Blues- ja Rock-kitaristeille, jotka tietävät miten non-master-volume-vahvistimien kanssa tullaan toimeen. Uudessa 18/30:ssa yhdistyvät 60-luvun Fender-kombojen parhaat ominaisuudet ja saman aikakauden brittiklassikkojen lihaksikkaan rouhea asenne.

Bassbreaker 18/30 -kombo ei sovi olohuoneen harjoittelukumppaniksi, ja myös kotistudioon se voi osoitauttua liian kovaääniseksi. Tämä on pro-luokan putkivahvistin, joka on tarkoitettu livekäyttöön sellaisissa paikoissa (ja bändeissä), joissa kitaristia ei alituiseen kehoteta soittamaan hiljempaa.

fender-bassbreaker-18_30-logo

*****
Fender Bassbreaker 18/30 Combo

suositushinta: 799 €

Lisätiedot: Fender

Paljon kiitoksia DLX Musiikille testivahvistimen lainaamisesta!

Plussat:

+ työnjälki

+ tyylikäs ulkonäkö

+ kotelo koivuvanerista

+ soundi

+ isotehoinen

Miinukset:

– isotehoinen

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

23/11/2016

Review: Fender Bassbreaker 18/30 Combo

fender-bassbreaker-18_30-top-logo

Imagine a brainstorming session at Fender R&D in sunny California, sometime in late 1966. The brief of the day is to come up with a new guitar amplifier.

One of the guys speaks up: ”I’m kinda bored of sparkling TV cowboys and clean-cut entertainers. How about we design an amp for the Blues and Rock players? I’ve heard some little company in England has been doing a sort of Bassman-on-steroids thing, and it seems to catch on. We should try to come up with something that really rocks, too!”

In reality that meeting never took place, but what if it had?

****

fender-bassbreaker-18_30-front

The new Fender Bassbreaker 18/30 Combo (list price in Finland: 799 €) could well have been the result of our imaginary R&D session.

The Bassbreaker 18/30 is like a visitor from a parallel universe, in which Fender has taken a turn in the mid-Sixties to design guitar amplifiers with a distinctly British accent.

This is a 2 x 12 Fender combo with a cool new trim, called Gray Tweed. The cabinet is built from birch ply, resulting in a combo with a still-manageable weight of just below 23 kg.

fender-bassbreaker-18_30-top

The Bassbreaker 18/30’s model name hints at the fact that this amp features two different Fender designs in one package:

Channel One of this two-channel amplifier is based on a Blackface Fender Deluxe and gives you 30 watts of output power. Channel Two on the other hand has been lifted from the earlier brown version of the Deluxe combo, and puts out 18 watts.

fender-bassbreaker-18_30-back

The Bassbreaker is an all-valve guitar amp with solid-state rectification, and it runs in Class A/B.

The preamp section is designed around a pair of 12AX7s, while the power amp uses a quartet of EL84s, instead of Fender’s more traditional 6V6 or 6L6 power tubes.

The back panel sports jack sockets for the channel-switching footswitch (included, as is an amp cover), external speaker cabinets, and a post power amp line level output.

fender-bassbreaker-18_30-valves-and-speakers

In addition to the more ”British accent” of the Bassbreaker 18/30’s power amp valves, Fender has also opted for a pair of chunky 12-inch Celestion V-Type speakers, instead of the Jensen and JBL models the company favoured in the 1960s.

****

fender-bassbreaker-18_30-control-panel

The 18/30’s Channel One – the Blackface channel – offers you a full three-band EQ-section for your clean tones, while Channel Two (”Brownface”) is more spartan with its single tone control.

fender-bassbreaker-18_30-angle-2

First, let me stress that the Fender Bassbreaker 18/30 is really very loud! This is a non-master volume tube combo, which lies in the same ballpark as similar amps, such as the Marshall 1962 Bluesbreaker or Vox AC30 combos, when it comes to sheer sound pressure levels.

The 18/30 really isn’t meant for living room use, because you need to raise Channel Two’s volume substantially, if you want to enjoy the combo’s tasty dirt. And this is despite the fact that this Bassbreaker combo shuts off two of its power tubes, whenever you engage Channel Two, in order to drop the amp’s headroom so it will distort earlier.

If high volume is an issue, but you still want a piece of that Bassbreaker action, I’d suggest you check out the Bassbreaker 15 combo, which comes with a master volume control.

At low volume settings both Bassbreaker 18/30 channels will give you clean tones, with Channel One having a brighter and more chimey voice, and Channel Two sounding a bit earthier. Thanks to the EL84 power amp, this isn’t your traditional Fender combo, but rather a mix of Fender character and UK-style mid-range growl and attitude.

Here’s a short clip of both channels set to clean (volumes between 9 and 10 o’clock) and played with a maple neck Stratocaster:

The demo song features two rhythm guitars – a Gibson Les Paul Junior (Channel One, stereo right) and a Fender Telecaster (Channel Two, stereo left) – and a lead guitar part, that has been played on an Epiphone Les Paul Standard with vintage-type EMG HZ-pickups through Channel Two (volume at 3 o’clock):

****

fender-bassbreaker-18_30-angle-1

Fender’s Bassbreaker 18/30 is a great-sounding guitar combo for the Blues and Rock guitarist, who knows how to coax great tones from an in-your-face non-master valve amp. The 18/30 manages to combine the best aspects of 1960s Fender amps with the chunk and grit usually associated with British designs.

The Bassbreaker 18/30 is too loud to be used as a bedroom or home studio amp. This combo has been designed as a professional tool for the gigging guitarist, who doesn’t have to ”turn it down” all the time.

fender-bassbreaker-18_30-logo

*****
Fender Bassbreaker 18/30 Combo

MSRP: 799 €

Contact: Fender

A big thank you to DLX Music Helsinki for the loan of the review combo!

Pros:

+ workmanship

+ design

+ birch-ply cabinet

+ sound

+ high volume levels

Cons:

– high volume levels

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

22/11/2016

Jam Track: Shuffle Blues in Bb (125 BPM)

22/11/2016

Now on SoundCloud: Fender Bassbreaker 18/30

Fender Bassbreaker
• Two-channel all-valve combo with solid-state rectification
• Channel 1 – 30 watts Blackface Deluxe-style
• Channel 2 – 18 watts Brown Deluxe-style
• Two 12″ Celestion V-Type speakers
• Two 12AX7 + four EL84
*******
Demo Song
• Rhythm guitars: Fender Telecaster on channel 2 (left) & Gibson Les Paul Junior on channel 1 (right); both channel volumes at 10 o’clock
• Lead guitar: Epiphone Les Paul Standard with vintage-style EMG HZ-pickups; channel 2, volume at 3 o’clock
*******
Clean Sounds
• Maple-neck Fender Stratocaster (middle + bridge PUs); both channel volumes at 9 o’clock

Contact: Fender

Fender Bassbreaker 18/30 control panel

Save

Save

09/11/2016

Review: Bluetone Shadows Reverb

For many guitarists the Vox AC30 is the greatest guitar amp ever made – bar none.

The combo was originally designed for the instrumental group The Shadows, but it became known worldwide as ”The Beatles Amp”. Over the decades, many other guitarists have favoured Vox’ best known design. Users include people like Brian May (Queen), Rory Gallagher and U2’s The Edge. Many Finnish Shadows-/Ventures-style bands (”rautalankka”) also favour the AC30.

Despite their legendary status, vintage Vox AC30s also do have their issues:

This large 2 x 12″ combo weighs quite a lot, making it a little hard to carry alone. Old Voxes also are non-master volume amps, which means that attaining natural distortion comes at the cost of serious sound pressure levels – often too much for small clubs and function gigs. Old AC30s also have all their valves – yes, also the power amp tubes – placed inside an almost completely closed metal chassis. This has led to vintage-Voxes getting an infamous reputation as relatively prone to catching fire.

vox-chassis-studiofreak-photobucket

(photo: Studiofreak/Photobucket)

Boutique amp makers Bluetone (from Helsinki, Finland) have recently come up with their special take on the beloved classic combo. Their new amp is called Bluetone Shadows Reverb, and it comes with a whole number of welcome improvements and modern features.

****

bluetone-shadows-reverb-front-angle

Bluetone’s Shadows Reverb (reviewed version: 1,950 €) is a single-channel all-valve amp loaded with a genuine spring reverb. The combo represents the company’s view of what constitutes a perfect Top Boost-channel tone, all presented in a much more compact format.

The Shadows Reverb is a class AB amp, and it offers between 15 and 30 Watts of output power, depending on the setting of its built-in Variac.

bluetone-shadows-reverb-back-angle

The combo’s cabinet is made from high-grade plywood. The Shadows Reverb is a good deal smaller and less deep than its classic forebear from the 1960s.

bluetone-shadows-reverb-speakers

This reduction in heft is due mostly to the use of 10-inch Celestion Alnico Gold speakers in place of the AC30’s 12-inch speaker pair.

The speakers in the Shadows Reverb combo have been ”played in” for a number of hours (using an oscillator) to get rid of the typical tightness of brand-new Alnico Golds.

bluetone-shadows-reverb-power-amp-valves

This Bluetone-combo uses three 12AX7-tubes, and a single 12AT7 in its preamp section.

bluetone-shadows-reverb-premp-valves-transformers

The power amp runs on a quartet of EL84 valves. The Shadows Reverb is a cathode-biased valve amp, which means that replacing the power amp tubes doesn’t usually necessitate any rebiasing.

****

bluetone-shadows-reverb-front-panel

Yes, the Bluetone Shadows Reverb is ”just” a single-channel combo, but it is far from a single sound guitar amplifier. In large part this is thanks to the brilliant modern features Bluetone has incorporated into this homage.

The Shadows Reverb offers you two guitar inputs – High and Low – for use with single coil- and humbucker-equipped instruments.

The preamp features a two-band Baxandall EQ-section – with typically interactive controls for Bass and Treble – as well as a three-stage Bass Cut rotary switch, which offers you two fatter alternatives to the famously bright and wiry Vox Top Boost sound.

The onboard spring reverb sounds fantastic and is a real treat to work with, giving you everything from completely dry tones to Surf Music antics.

The power amp section comes with three controls:

Cut allows you to make overall adjustments to the combo’s treble output.

Bluetone’s Master Volume-control is placed after the phase inverter, right at the end of the signal chain. This allows you to get juicy power amp distortion at low volume levels, and with only minimal changes in the amp’s tone.

As mentioned before, the Shadows Reverb comes with a built-in Variac circuit. Although the Variac also has a bearing on the combo’s output level, it works in a completely different way to the master volume, namely by dropping the voltage the power amp runs on. Turning the Variac down will result in a good deal less clean headroom and more power amp sag.

Due to large public interest, I had to return the Shadows Reverb much earlier than anticipated, but I still managed to record two different demo tracks with the Bluetone amp.

The first (clean) track features rhythm guitar tracks played on a Fender Telecaster (left channel) and a 1970s Japanese copy of a Gibson ES-335 (Kasuga; right channel). The lead guitar part was played on a Fender Stratocaster. All guitar tracks have been recorded with an AKG C3000 microphone placed approximately 80 cm from the combo’s front:

The second track (overdriven) has been recorded with a Stratocaster. The distortion comes from the Shadows Reverb (no pedals used), and all tracks have been close-miked with a pair of Shure SM57s:

bluetone-shadows-reverb-master-section

****

Bluetone’s Shadows Reverb is an outstanding boutique amp take on the Vox AC30 motif. Like all other Bluetone amps, the Shadows Reverb is carefully handmade in Finland to the company’s strict quality standards. This results in reliable top-drawer tools for the musician, with extremely low levels of hiss and negligible AC hum.

I had a great time test driving this combo. The Bluetone Shadows Reverb simply delivers all it promises with style and panache. The combo weighs approximately half of the original classic (AC30s usually weigh between 31 to 36 kg, depending on their specific vintage and the speakers they come loaded with). The reduced size means you won’t be having any problems lifting this beauty into the boot of a small car, such as a Ford Fiesta.

Thanks to the additional features of this Bluetone combo – like the Bass Cut and the Variac – you will be able to enjoy the great sound of the Shadows Reverb anywhere you want, be it at home or on stage.

****

Bluetone Shadows Reverb

Prices starting at approx. 1,700 € (reviewed version: 1,950 €)

Manufacturer: Bluetone Amps

****

Pros:

+ handmade in Finland

+ size

+ weight

+ valve-powered spring reverb

+ Variac- and Master Volume-controls

+ sound

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

04/11/2016

Testipenkissä: Bluetone Shadows Reverb

Monelle kitaristille Voxin AC30-kombo on se yksi ja ainoa varteenotettava kitaravahvistin.

Alun perin brittiyhtye The Shadowsia varten kehitetty AC30 tuli kuuluisaksi The Beatles -vahvistimena, mutta se on löytänyt tiensä monien erityylisten kitaristien backlineen. Tunnetuimpiin käyttäjiin kuuluvat mm. Brian May (Queen), Rory Gallagher sekä U2:n The Edge. Myös Suomen rautalankabändien keskuudessa AC30 kuuluu vakiovarustukseen.

Suosiosta huolimatta vanhoilla AC30-komboilla on myös huonot puolensa:

Isokokoinen, kahdella 12-tuumaisella kaiuttimella varustettu putkikombo on melko painava ilmestys. Vanhoissa Voxeissa ei myöskään ole master volume -säädintä, mikä tarkoittaa sitä että vahvistimen omaa säröä pystyy hyödyntämään asianmukaisesti vain isoissa keikkapaikoissa. Lisäksi vintage-Voxeissa kaikki putket – kyllä, myös pääteputket – on sijoitettu lähes kokonaan suljettuun metallikoteloon, minkä takia vintage-AC30:t voivat (käyttötavasta rippuen) syttyä palamaan herkemmin kuin moni muu vanha kombovahvistin.

vox-chassis-studiofreak-photobucket

(kuva: Studiofreak/Photobucket)

Helsinkiläinen vahvistinpaja Bluetone tarjoaa nyt oivan ratkaisun klassikkovahvistimen ongelmiin Bluetone Shadows Reverb -nimisen putkikombon muodossa.

****

bluetone-shadows-reverb-front-angle

Bluetone Shadows Reverb (testattu versio: 1.950 €) on yksikanavainen, jousikaiulla varustettu täysputkikombo, joka lupaa aitoa Top Boost -soundia selvästi pienemmässä paketissa ja nykyaikaisilla ominaisuuksilla höystettynä.

Shadows Reverb on AB-luokan vahvistin, joka tarjoaa 15-30 wattia tehoa, riippuen Variac-säätimen asennosta.

bluetone-shadows-reverb-back-angle

Shadows Reverbin kaiutinkotelo tehdään vanerista, ja se on selvästi pienempi ja litteämpi kuin 1960-luvun esikuvansa.

bluetone-shadows-reverb-speakers

Pienempi koko on osittain mahdollistettu käyttämällä klassikkokombon 12-tuumaisten kaiuttimien sijaan 10-tuumaisia Celestion Alnico Gold -kaiuttimia.

Shadows Reverbin kaiuttimia on, siniaaltogeneraattoria käyttäen, ajettu sisään useamman tunnin ajan, minkä ansiosta on saatu vähennettyä uusille Alnico Gold -elementeille tyypillistä alkukireyttä.

bluetone-shadows-reverb-power-amp-valves

Tässä Bluetonessa käytetään etuasteessa kolmea 12AX7-putkea, sekä yhtä 12AT7:ää.

bluetone-shadows-reverb-premp-valves-transformers

Päätevahvistin tuottaa tehonsa neljän EL84-putken voimalla. Shadows Reverb on katodibiasoitu kombo, mikä tarkoittaa sitä, ettei pääteputkia yleensä tarvitse biasoida vaihdon yhteydessä.

****

bluetone-shadows-reverb-front-panel

Vaikka Bluetone Shadows Reverb on ”vain” yksikanavainen kombo, sen soundimaailma on selvästi laajempi kuin uskoisi. Kiitos siitä kuuluu Bluetonen monipuolisille ominaisuuksille.

Shadows Reverb tarjoaa kaksi kitaratuloa – High ja Low – single coil- ja humbucker-mikrofoneja varten.

Etuasteesta löytyy kaksikaistainen Baxandall-EQ – interaktiivisilla basso- ja diskanttisäädöillä – sekä kolmiasentoinen Bass Cut -bassoleikkuri, joka tarjoaa aidon Vox Top Boost -soundin lisäksi kaksi hieman muhkeampaa vaihtoehtoa.

Reverb-säätimellä hallitaan kombon putkivahvistettua jousikaikua. Kaiun soundi on erinomainen, ja säätimen skaala yltää täysin kuivasta kaikuisaan Surf-vatkaukseen.

Päätevahvistimelle on varattu jopa kolme säädintä:

Cut-säätimellä voidaan säännöstellä kombon kokonaisdiskanttia.

Bluetonen Master Volume -säädin on signaaliketjun loppupäässä (vaihekääntäjän jälkeen), ja sen ansiosta voidaan tuottaa päätesäröä myös pienillä volyymeillä.

Shadows Reverbissä on myös kolmiasentoinen Variac-tehonsäädin. Variac toimii eri tavalla kuin perinteinen master volume -säädin, se nimittäin muuttaa pääteasteen sisäistä jännitettä. Tehoa laskettaessa päätevahvistimen puhdas headroom ja putkikompressio muuttuvat.

Testikombon palautuksen suhteen tuli ylättäen hieman kiire, mutta ehdin kuitenkin äänittää kaksi erilaista demobiisiä Bluetone Shadows Reverbillä.

Ensimmäisessä kappaleessa komppikitarat soitettiin Fender Telecasterilla (vasen kanava) ja vanhalla japanilaisella puoliakustisella (Kasuga, oikea kanava). Soolokitarana toimi Fender Stratocaster:

Toisessa biisissä särösoundi tulee pelkästään kombosta itse. Kaikki raidat on soitettu Stratolla:

bluetone-shadows-reverb-master-section

****

Bluetone Shadows Reverb -kombo on erinomainen boutique-luokan muunnelma Vox AC30 -teemasta. Kuten muutkin Bluetone-vahvistimet, Shadows Reverb rakennetaan kokonaan käsin Suomessa tiukkojen laatustandardien mukaan, mistä kielivät mm. kombon erittäin alhainen kohinataso, sekä käytännössä olematon verkkohumina. Vahvistimen laatuun suhteutettuna pidän Shadows Reverbin hintaa erittäin reiluna.

Testikokemuksen perusteella voin vain todeta, että Bluetone Shadows Reverb lunastaa lupauksensa avokätisesti ja tyylikkäästi. Bluetone-kombo painaa lähes tarkalleen puolet vanhan klassikon painosta (AC30 painaa noin 31-36 kg, vuosimallista ja kaiutinvarustuksesta riippuen), ja sen pienempi koko tarkoittaa, että Shadows Reverb mahtuu helposti esimerkiksi Ford Fiestan takakonttiin (kokeiltu on).

Bluetonen lisäominaisuuksien – kuten bassoleikkurin ja Variacin – ansiosta Shadows Reverbin tarjoama soundikattaus on yllättävän laaja, ja kombon erinomaisista soundeista voi nauttia sekä omassa olohuoneessa että keikkalavalla.

****

Bluetone Shadows Reverb

Hinnat alk. 1.700 € (testattu version 1.950)

Valmistaja: Bluetone Amps

****

Plussat:

+ käsintehty Suomessa

+ koko

+ paino

+ jousikaiku

+ Variac ja Master Volume

+ soundi

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save

Save
